Ri-Lam M100 R9 Floor Talker Anti Slip Lamination Film has been specially developed to protect digitally printed floor graphic images.
It provides anti-slip properties (classified R9 according to DIN 51130:2014) and has a transparent monomeric calendered vinyl face film.
It is perfect for use with Ri-Jet M100 printed media when printed with solvent, eco-solvent and latex inks, but is not suitable for UV print due to silvering.
REACH and RoHS compliant.
Ri-Lam M100 R9 Floor Talker Anti Slip Lamination Film has been specially developed to protect digitally printed floor graphic images.
It provides anti-slip properties (classified R9 according to DIN 51130:2014) and has a transparent monomeric calendered vinyl face film.
It is perfect for use with Ri-Jet M100 printed media when printed with solvent, eco-solvent and latex inks, but is not suitable for UV print due to silvering.
REACH and RoHS compliant.
Typical use:
• Short term indoor floor graphic
• Provide anti-slip properties, classified R9
• Protect printed media from abrasion and retard colour fading
• Provide homogeneous finish
Construction:
• Face film: 100 μm structured monomeric calendered vinyl
• Adhesive: permanent clear water-based acrylic
• Release liner: glassine 62 g/m2
Converting method:
Compatible with solvent, eco-solvent and latex inks.
To be laminated with a laminator.
Application method/instructions for use:
The printed media to laminate should dry minimum 24h prior to lamination.
Laminate without tension on the printed media.
Expected durability:
The expected indoor durability is 6 months.
This information is based on real file experience and artificial aging according to ISO 4892-2.
Note: Exposure to severe temperature and ultra-violet light will cause a quicker deterioration. This applies also to polluted area, high altitude, horizontal applications, and south-facing exposure.
Shelf life:
Shelf life is 2 years, when stored at 23 °C and 50 % relative humidity conditions.
Higher temperatures and/or humidity levels will reduce product shelf life.
Product specification for RI-Lam M100 R9 Floor Talker Anti Slip Lamination Film
Download the full specification for RI-Lam M100 R9 Floor Talker Anti Slip Lamination Film
Within these Ritrama Digital Media printing guidelines, we cover proper media handling, printing setup, and finishing processes that will help to achieve optimal print quality and performance. These guidelines cover aspects like media profiles, drying times, application techniques, and troubleshooting.
1. Print Preparation:
Media Profiles:
Ensure the correct media profile is installed and selected in your print server. This profile contains information about the printer, RIP, ink, and the specific Ritrama media being used.
Drying:
For solvent printing, films need to be fully dried before applying overlaminates. A 24-hour drying time is generally sufficient for full solvent inks, while 48 hours is recommended for eco-/mild solvent inks. Allow for longer drying if a lot of ink is deposited.
Winding:
When drying, avoid tightly winding the material on a core, as this can hinder solvent evaporation. Loosely wound or stacked sheets are preferred.
2. Printing:
Resolution: For sharp, clear images, a resolution of 300 dpi is recommended.
Colour Matching: Digital printing may have limitations in achieving precise Pantone or specific colour shades.
3. Finishing:
Overlaminates:
If applying overlaminates, ensure the printed material is thoroughly dry to prevent potential issues.
Cutting:
For cutting, ensure the blade is clean and sharp.
Stabilisation:
After curing, allow 4-8 hours for the ink and substrate to stabilize before die-cutting, pre-masking, or chemical resistance testing.
4. Application:
Surface Preparation: Clean the substrate thoroughly before applying the media.
Application Tools: Use a squeegee with overlapping strokes, applying moderate pressure.
Temperature: Avoid applying films in extreme temperatures. If necessary, use a heat gun to gently warm the material during application.
Troubleshooting: If bubbles or wrinkles occur, try using a heat gun to help eliminate them. It may be possible to reposition some products, or push air bubbles out towards the edge of the media.
5. Cleaning and Maintenance:
Cleaning:
Use a gentle cleaning solution (water with a small amount of soap) and a soft cloth. Avoid using harsh chemicals or abrasive materials.
Pressure Washing:
Use pressure washing with caution, keeping pressure below 1200 psi and water temperature below 120° F.
6. Additional Tips:
Testing:
Thoroughly test all performance characteristics, including print quality, durability, and chemical resistance, before each production run.
