Avery MPI 1104 Easy Apply Repo Vehicle Wrap 1370mm x 50m (AZ7230001)
Central UK Location
Daily deliveries throughout
the UK and Europe
Avery Dennison® MPI™ 1104 Series cast films are gloss white, highly conformable, self-adhesive vinyls for digital printing. The films deliver great printability and image quality. As part of the new generation Digital Cast Films, they cope easily with 3D challenges such as rivets and corrugations.
50 metres on a full roll.
Printed samples available upon request.
 |
Click here for a matching print and laminate bundle pack |
Avery Dennison® MPI™ 1104 Series cast films are gloss white, highly conformable, self-adhesive vinyls for digital printing. The films deliver great printability and image quality. As part of the new generation Digital Cast Films, they cope easily with 3D challenges such as rivets and corrugations.
Best-in-class conformability and Easy Apply technology give you outstanding performance across a wide range of indoor and outdoor applications.
MPI 1100 Cast series consists of gloss white, highly conformable self-adhesive cast vinyls. The face film has been especially developed for exceptional print results on all major printer platforms using Latex, EcoSolvent, Hard Solvent and UV-Curing inks. MPI 1104 Easy Apply is recommended for applications on rivets and corrugations, without the need for additional application of primers or incisions. Due to the repositionable permanent adhesive the film is easy to position during application.
Avery Dennison MPI 1100 series cast films have been designed to deliver an outstanding & consistent print performance across all major wide format inkjet printer platforms. To enhance colour and to protect images against UV radiation and abrasion, Avery Dennison MPI 1100 Cast films are recommended to be protected using an overlaminate. If the final graphic is used on corrugated vehicles or substrates, Avery Dennison DOL 1460 Z Gloss or Avery Dennison DOL Z 1480 Matt conformable laminates are recommended to protect the graphic and enhance its life span. Do NOT use wet application methods for Avery Dennison Easy Apply products.
- Excellent printability and handling on select printers
- Outstanding durability and outdoor performance
- Excellent conformability to irregular substrates
- High performance adhesive sticking to low energy, apolar and rough surface which with normal adhesives cannot be covered (e.g. bumpers or mirrors on cars for a complete wrap
- ICS Performance Guarantee
Uses
- Full vehicle wraps
- Vehicle graphics
- Interior and exterior decorative architectural applications
- All permanent applications requiring high conformability
FAQ
Avery Dennison’s Easy Apply technology refers to air channels in the adhesive layer, this helps avoid wrinkles, and allows for trapped air to be removed, without the need to pierce the film.
Avery MPI 1004 Easy Apply Repositionable is 50 microns thick, excluding the adhesive backing.
Avery MPI 1104 Easy Apply has a rated service life of up to 7 years, vertically mounted, under outdoors conditions.
Avery MPI 1104 Easy Apply Repositionable comes in 1520mm and 1370mm widths, with 50 meters on a full roll.
Avery MPI 1104 Easy Apply Repositionable Super Cast has a rated life-span of 7 years vertically mounted in outdoors conditions.
Avery MPI 1104 Easy Apply Repositionable should be used in conjunction with the Avery DOL 1400 cast lamination film as it features the same 3D conformability and longevity.
Product Specification
Download a full product specification here
Avery MPI 1104 Product overview
Product overview for Avery MPI 1104
Application of Avery Dennison MPI Cast films on irregular substrates
This document contains essential information about surface preparation, print preparation and application.
Avery MPI 1104 Easy Apply Product Specification
Download the full product specification for Avery MPI 1104 Easy Apply here
Avery Dennison Digital Media printing guidelines emphasise proper media handling, printing setup, and finishing processes to ensure optimal print quality and performance. These guidelines cover aspects like media profiles, drying times, application techniques, and troubleshooting.
1. Print Preparation
Media Profiles
Ensure the correct media profile is installed and selected in your print server. This profile contains information about the printer, RIP, ink, and the specific Avery Dennison media being used.
Drying
For solvent printing, films need to be fully dried before applying overlaminates. A 24-hour drying time is generally sufficient for full solvent inks, while 48 hours is recommended for eco-/mild solvent inks. Allow for longer drying if a lot of ink is deposited.
Winding
When drying, avoid tightly winding the material on a core, as this can hinder solvent evaporation. Loosely wound or stacked sheets are preferred.
2. Printing
Resolution
For sharp, clear images, a resolution of 300 DPI is recommended.
Colour Matching
Digital printing may have limitations in achieving precise Pantone or specific colour shades.
3. Finishing
Overlaminates
If applying overlaminates, ensure the printed material is thoroughly dry to prevent potential issues.
Cutting
For cutting, ensure the blade is clean and sharp.
Stabilisation
After curing, allow 4-8 hours for the ink and substrate to stabilize before die-cutting, pre-masking, or chemical resistance testing.
4. Application
Surface Preparation
Clean the substrate thoroughly before applying the media.
Application Tools
Use a squeegee with overlapping strokes, applying moderate pressure.
Temperature
Avoid applying films in extreme temperatures. If necessary, use a heat gun to gently warm the material during application.
Troubleshooting
If bubbles or wrinkles occur, try using a heat gun or repositioning the film with the Avery Dennison Easy Apply™ or RS technology.
5. Cleaning and Maintenance
Cleaning
Use a gentle cleaning solution (water with a small amount of soap) and a soft cloth. Avoid using harsh chemicals or abrasive materials.
Pressure Washing
Use pressure washing with caution, keeping pressure below 1200 psi and water temperature below 120° F.
6. Additional Tips
Testing
Thoroughly test all performance characteristics, including print quality, durability, and chemical resistance, before each production run.
