Avery MPI 1105 EARS Super Cast Vehicle Wrap 1370mm x 50m UD2954
Central UK Location
Daily deliveries throughout
the UK and Europe
The ultimate wrapping solution - new MPI 1105 Wrapping series films bring new levels of printability, image quality and 3D conformability to vehicle wraps. Outstanding colour ‘pop’ and an ability to cope easily with challenges such as rivets and corrugations make MPI 1105 the product of choice across many different applications.
50 metres on a full roll.
Printed samples available upon request.
The ultimate wrapping solution - new MPI 1105 Wrapping series films bring new levels of printability, image quality and 3D conformability to vehicle wraps. Outstanding colour ‘pop’ and an ability to cope easily with challenges such as rivets and corrugations make MPI 1105 the product of choice across many different applications.
New MPI 1105 now offers up to 6 years printed* durability. In combination with improved DOL 1460 Z Gloss and DOL 1480 Z Matt overlaminates, it enables an even longer lifespan for vehicle graphics, opening up a world of wrapping applications for customers and end-users.
Key features
- Superb 3D conformability
- Stunning and consistent printability
- UV, solvent, eco-solvent and latex inks compatible
- Easy Apply RS™ adhesive technology with air-egress, repositionability and slideability
- Reliable performance with long-term removability
- Maximum outdoor durability, up to 6 years printed*
- Covered by ICS Performance Guarantee
Key benefits
- Faster, easier installation, conforming to the most demanding corrugations
- Up to 30% application time savings with Easy Apply RS™ technology and its air-egress capability
- Ease of application with low initial tack, repositionabilty & slideability
- Creative freedom thanks to outstanding printed image quality and longer printed graphics lifespan (up to 6 years*)
*vertical printed durability, zone 1, in combination with DOL 1460/1480 Z series
Recommended uses
- Partial and full vehicle wraps
- Interior and exterior signs
FAQ
Laminating Avery MPI 1105 Super Cast helps to protect the print from weathering and damage, as well as UV Radiation from the sun. Your colours will stay brighter for longer with a laminate applied.
You should use Avery MPI 1105 Easy Apply Repositionable digital with the Avery DOL 1460 cast lamination film.
You should be storing Avery MPI 1105 Easy Apply Repositionable Super Cast at 20° C with a relative room humidity of 50%.
Avery MPI 1105 Easy Apply Repositionable Super cast digital is 50 microns thick, face film only.
Avery MPI 1105 Easy Apply Repositionable Super Cast has a rated life-span of 10 years vertically mounted in outdoors conditions.
Avery MPI 1105 Easy Apply Repositionable Super Cast can be printed to using UV, Latex, Eco-Solvent and hard solvent inks.
Avery MPI 1105 Product Specification
Download a full product specification for Avery MPI 1105 here
Avery Portfolio Overview
Download the Avery Portfolio Overview here
Avery Dennison MPI 1105 Wrapping Series
Overview of the Avery MPI 1105 wrapping range
Application of Avery Dennison MPI Cast films on irregular substrates
This document contains essential information about surface preparation, print preparation and application.
Avery Dennison Digital Media printing guidelines emphasise proper media handling, printing setup, and finishing processes to ensure optimal print quality and performance. These guidelines cover aspects like media profiles, drying times, application techniques, and troubleshooting.
1. Print Preparation
Media Profiles
Ensure the correct media profile is installed and selected in your print server. This profile contains information about the printer, RIP, ink, and the specific Avery Dennison media being used.
Drying
For solvent printing, films need to be fully dried before applying overlaminates. A 24-hour drying time is generally sufficient for full solvent inks, while 48 hours is recommended for eco-/mild solvent inks. Allow for longer drying if a lot of ink is deposited.
Winding
When drying, avoid tightly winding the material on a core, as this can hinder solvent evaporation. Loosely wound or stacked sheets are preferred.
2. Printing
Resolution
For sharp, clear images, a resolution of 300 DPI is recommended.
Colour Matching
Digital printing may have limitations in achieving precise Pantone or specific colour shades.
3. Finishing
Overlaminates
If applying overlaminates, ensure the printed material is thoroughly dry to prevent potential issues.
Cutting
For cutting, ensure the blade is clean and sharp.
Stabilisation
After curing, allow 4-8 hours for the ink and substrate to stabilize before die-cutting, pre-masking, or chemical resistance testing.
4. Application
Surface Preparation
Clean the substrate thoroughly before applying the media.
Application Tools
Use a squeegee with overlapping strokes, applying moderate pressure.
Temperature
Avoid applying films in extreme temperatures. If necessary, use a heat gun to gently warm the material during application.
Troubleshooting
If bubbles or wrinkles occur, try using a heat gun or repositioning the film with the Avery Dennison Easy Apply™ or RS technology.
5. Cleaning and Maintenance
Cleaning
Use a gentle cleaning solution (water with a small amount of soap) and a soft cloth. Avoid using harsh chemicals or abrasive materials.
Pressure Washing
Use pressure washing with caution, keeping pressure below 1200 psi and water temperature below 120° F.
6. Additional Tips
Testing
Thoroughly test all performance characteristics, including print quality, durability, and chemical resistance, before each production run.
